Josawa ALFW-550P

The ALFW-550P is a 2×50-watt active surface mount speaker set featuring balanced audio inputs and a powerful stereo speaker system.

Description

The ALFW-550P is a 2×50-watt active speaker set featuring balanced audio inputs and a powerful stereo speaker system, making it ideal for meeting rooms, conference rooms, classrooms and similar environments.

Despite its compact design, the ALFW-550P delivers excellent sound performance through integrated 2-way speakers units. The system combines a dedicated bass woofer with a midrange and tweeter driver, providing clear vocal, detailed highs and strong low-frequency response. Included speaker mounts allow for flexible installation, enabling placement on a desktop or secure wall mounting.

Features:

  • 2 x 50-watt active speakers
  • Automatic standby mode after 5 minutes without signal (0.5 watt)
  • Audio inputs: Bluetooth, 1 x RCA + 1 x Stereo 3,5 mm + 1 x Balanced LOOP and Sub output
  • One pair of speakers (one active + one passive)
  • Remote Control
  • Available in White / Black

Specifications

General specifications
Frequency Response 60Hz~20KHz@-10dB, 70Hz ~20kHz@-3dB
Sensitivity 87dB
Rated Power 2 × 50 Watt (4Ω)
Nominal Coverage Angle Horizontal 90 × Vertical 60 @ -6dB
Max SPL (sound pressure level) 1m distance 104dB
Power Supply 110~240 Volt AC
Power Consumption Working ≦ 150 Watt, Standby ≦ 0.5Watt
Signal In 1 × RCA, 1 × Optical, 1 × USB
Signal Out 1 × LOOP & 1 × SUB OUT
Speaker Output 2 PIN Phoenix
Dimensions (W × D × H) 160 × 145 × 260mm
Physical specifications
Component Bass 5.25″
Tweeter 1.0″
Material Enclosure Plastic
Mounting panel Aluminum mesh & installation bracket
Color Black / White
Unit Weight 2.67kg
Gross Weight 13.1kg / 4pcs
Packing Dimension 57.5 × 49 × 32.5CM
Accessories Remote control, aluminum stand, AC power cord
Woofer speaker specifications
Voice Coil Size 25.9 × 0.23mm EISV / 2 Layer CW
DC Impedance 4.2Ω
Former ASV
Magnet 90 × 32 × 16 Y30
Basket Iron
Cone Material Paper cone with PP coating, rubber surround
Spider 65%PET + 35%COTTON
Net Weight 1.05Kg
Tweeter speaker specifications
Voice Coil Size 25.5 × 0.10 EISV / 2 Layer CCAW
DC Impedance 7.2Ω
Former KATON
Magnet 24.5 × 3.5 N35
Cone Material Silk surround + Titanium
Net Weight 0.0485Kg
