Name: ALF-MU4K HUB - Josawa
SKU: ALF-WU4K HUB-8K(Coming Soon)

Description

The ALF-MU4k HUB is an HDM2.0 conference switching hub, with 4 inputs, two outputs, Multiview & USB KVM Hub. It supports up to 4K resolutions.

Product Features

HDMI 2.0, 18G, 4K@60 4:4:4, HDCP2.3 and backward compatible
Seamless switching between the inputs
2 HDMI Mirrored outputs
Multview with different modes selection and user define setting
KVM switching at 10G bps
KVM auto-switching based on TMDS/5V detection
KVM supports hot-key control (only for the USB2.0 port)
De-embedded audio with digital and analog
EDID & HDCP management via DIP switch
Supports Auto switching for the inputs
TCP/IP (GUl) & RS232, buttons & GPIO control
Support HDR
Support CEC control
TCP/IP is to allow the FW upgrade to be done over the network & to be discoverable via third part management system
Including 24V 2A PSU

Specifications

VIDEO
HDMI Input	1. HDMI V2.1, supports resolution up to 4K@60Hz 4:4:4, HDR 10 and Dolby Vision. 2. Supports up to LPCM 7.1, Dolby® TrueHD, Dolby Digital® Plus, and DTS-HD® Master Audio™ .
USB-C	1. Supports up to 4K UHD 60Hz 4:2:0.
AUDIO
HDMI Audio	Supports up to LPCM 7.1, Dolby® TrueHD, Dolby Digital® Plus, and DTS-HD® Master Audio™ .
Optical	Supports up to LPCM 7.1, Dolby® TrueHD, Dolby Digital® Plus, and DTS-HD® Master Audio™ .
Analog (Balanced)	PCM 2.0 CH
USB
USB supports USB3.2, bandwidth up to 10G bps
HDCP
HDCP Management	Input: HDCP 2.3 and backward compatible
	Output: Manageable (Default follow the display). For example: it will output HDCP 1.4 when source is HDCP 2.3 or 2.2 when connect to HDCP 1.4 display. It will turn off HDCP if display does not support HDCP.
	Can turnoff HDCP by DIP switch compulsory
EDID	Provided when project starts
Management
GUI	CUI control is available
USB	The firmware can be updated
Operating temperature	When testing on Room temperature, the average temperature at the top of the housing is 41.5°, the bottom averages 45.2°.

Coming Soon!
