ALF-DSP88-U

Category:

ALF-DSP88-U

The ALF-DSP88-U Audio Digital Signal Processor (DSP) is equipped with several core technical features to simulate the work of an audio engineer. The ALF-DSP88-U consists of 8 analogue inputs and 8 analogue outputs, USB Audio, 8 General Purpose Input / Output (GPIO) connections, RS-232, RS-485, and IP control. With two ADI SHARC 21489 processors, it is equipped with advanced audio processing modules including Acoustic Echo Cancellation, Noise Suppression, and Auto Mixing. The Analogue to Digital (A/D) and Digital to Analogue (D/A) convertors on the Input and output stage of the ALF-DSP88-U features 48kHz sampling rate and a bit rate of 24Bits, providing high definition audio sampling and processing. It also has a dynamic range of 110dB and a maximum level of +24dBu. It features input and output processing modules including: Expanders, Compressors, Acoustic Gain Compensation (AGC), Parametric EQ, Feedback Suppression, Ducker, Gate, Ambient Noise Compensation, Graphic EQ, and Delay. DSP-based audio management, routing, processing, and control, is facilitated via a computer running the GUI Software for the ALF-DSP88-U Hardware. The DSP Controller software is a Windows-based application, which is used to configure and control the ALF-DSP88-U. The DSP Controller is a full-feature application, including parameter adjustments and peripheral accessory settings of all modules, such as RS232, RS485, and click-and-drag panel configuration. The most interesting part is the user interface which allows the engineer to customize the user interface so that the integrator can edit it; or the onsite technicians, or end users can operate it. Advanced security features make it possible for the end user to only access the controls allowed by the engineer, or the designer.

Product Features:

  • Includes two ADI SHARC 21489 Audio Processors
  • 8 Balanced Mic / Line Inputs and 8 Balanced Line outputs on phoenix (PCB) connections
  • 24Bit, 48kHz A/D and D/A convertors
  • 1ch. USB input and output
  • Advanced Audio Processing incl. AEC, Auto-Mixing, Noise Suppression, Matrix
  • Audio Processing Modules include:
    • Expanders
    • Compressors
    • Acoustic Gain Compensation (AGC)
    • Parametric EQ
    • Feedback Suppression
    • Ducker
    • Gate
    • Ambient Noise Compensation
    • Graphic EQ
    • Delay
  • Software GUI Interface for easy setup and control of all DSP features.
  • RS-232, RS-485, and IP Control.
  • 8 GPIO connections

Optional:

  • External volume controls and keypads are available separately

Specification

Technical Specifications

Processor ADI SHARC 21489(x2)
A/D and D/A Convertors

(Sampling rate / Digitalizing bit)

 48kHz  / 24Bit
Input Gain 0 – 48dB in 3dB Steps
Phantom Power 48V
Frequency Response (20~20KHz) ±0.2dB
Maximum Level +24dBu
THD + Noise 0.003%@4dBu
Dynamic Range 110 dB
Background Noise (A-weighted) -91 dBA
Common Mode Rejection Ratio @60Hz 80dB
Channel Isolation @1KHz 108 dB
Input Impedance (Balanced Connection) 9.4KΩ
Output Impedance (Balanced Connection) 102Ω
System Delay <3ms
Inputs 8 Balance Line/Mic Inputs on Phoenix Connections
Outputs 8 Balance Line Outputs on Phoenix Connections
Audio Processing Functions



 Acoustic Echo Cancellations (AEC) – Single Channel

Automatic Gain Control (AGC)

Noise Suppression

Auto Mixer

Matrix

8 Band Parametric EQ (Inputs & Outputs)

High / Low Shelf Filters

Expander

Compressor / Limiter

Feedback Suppressor

Delay
USB AUDIO 1 In – 1 Out
Control Options IP based PC software and host control.

Third party control for RS-485 and RS-232.
GPIO 8 Channel Logic Output

Mechanical

Working Power AC110~240V 5Hz-60Hz
Maximum Power Consumption <40W
Rack Space Required 1U
Dimensions (Width x Depth x Height) 482 x 260 x 45mm
Shipping Weight 3KG

Software Requirements

A Windows PC with:

  • Intel i5 processor or higher
  • 8 GB or higher memory
  • 1 GB free storage space
  • Windows 7 or higher version
  • Minimum 1920 x 1080 resolution
  • 24 bit or higher color
  • Network (Ethernet) port

Software Installation:

Visit the device web page address: 169.254.10.227

  1. Download software from the Josawa website and install files.
  2. Double click the downloaded file and install by following the instructions on the screen.

After the software is installed, read other parts of the help file, or execute the software.

After the software is installed, use one of the following methods to open the software:

  1. Double Click Desktop Icon
  2. Open from Start menu

Resources

Downloads

Download the Josawa DSP software installation file here:

JOSAWA DSP Software



Minimum PC Requirements

A Windows PC with:

  • Intel i5 processor or higher
  • 8 GB or higher memory
  • 1 GB free storage space
  • Windows 7 or higher version
  • Minimum 1920 x 1080 resolution
  • 24 bit or higher color
  • Network (Ethernet) port

Software Installation:

  1. Download software from the link above.
  2. Unzip the downloaded file and double-click to install and follow the instructions to complete installation.

After the software is installed, use one of the following methods to open the software:

  1. Double-click the JOSAWA DSP3.0 desktop Icon
  2. Open the JOSAWA DSP3.0 app from Start menu

APP Control

iOS APP – DSP Pro V2  app is available for download from iOS.

Android APP – DSP Pro V2 app (phone and tablet apk) download here.

Accessories

Josawa ALF-CP1L

The wall mounted ALF-CP1L control panel consists of a 1.3” OLED screen and a rotary encoder with Push-to-Select. The 2-line OLED provides customizable menus and sub-menu controls of Volume, routing, presets and more. Easily programmed and managed from the Josawa DSP software using a single CAT5 connection for control and power.
