ALF-CMW101

Category:

ALF-CMW101

The ALF–CMW101 is a full HD web camera equipped with a 120˚ wide-angle lens, and comes with a 2.4GHz wireless speakerphone. This Video Conference system is suitable for small to medium-sized conferences as well as personal business and family solutions.

The ALF-CMW101 is compatible with video meeting software, such as Teams, GoToWebinar, and Zoom. The 1080P HD camera is equipped for high-quality video stream and high definition real-time synchronization, and the 2.4GHz wireless speakerphone has up to a 3m pickup range

Product Features

  • It has a mechanically adjustable lens. The lens can be adjusted vertically from -30 to 30 degrees and horizontally from -150 to 150 degrees vertically; this enables flexible angle adjustments.
  • The Microphone has a 360-degree pickup with 256ms acoustic echo cancellation.
  • Full duplex with Dynamic Noise Reduction (DNR).
  • Plug and Play. No need for any drivers.
  • Supplied with one Speakerphone
  • Can be mounted to the top of a display with the included bracket or 1/4 mounting hole at the bottom of the bracket.



OBS SOFTWARE COMPATIBLE

7 YEAR WARRANTY

Specifications

Specification Description
Dimension Camera: 104* 139* 124mm Speakerphone: 155* 148* 37mm
Net weight Camera: 500g

Speakerphone: 337g
Color Black
Interface USB 2.0
Cable Length 2m
Battery(speakerphone) Built-in lithium battery (7-10H)
Lens 1/2.8, fixed focus, 120 degrees Angle
Sensor Full HD CMOS sensor
Voice pickup range 3m max
Video 1920 * 1080
Image transmission speed Up to 30FPS
Aperture coefficient F2.0
Focus distance 30～300CM (Better distance）
Computer system Windows ® 7, 10 / Mac OS X 8.1 or 10.7 or higher operating system, etc
Recommended conditions Humidity：20~85%

Condensation free Noise level：<48dB

Storage temperature：-10°~55°

Reverberation time:  <0.5 seconds
Certification CE/FCC

Gallery

Hi-Res Image Here

Resources

FAQ's

1.  Q – Is the camera remote controllable?
     A – No, the lens can be physically adjusted vertically and horizontally.

2.  Q – What is the output resolution on the camera?
     A – Full HD – 1920 x 1080p

3.  Q – What is the ideal seated space from the camera?
     A – The object distance should be no more than 3m away.

4.  Q – I cannot see the microphone, where do I speak into?
     A – The speakerphone has a 360 degree pick up field.

5.  Q – Can I connect via Bluetooth to the speakerphone?
     A – No, the speaker phone is not Bluetooth enabled.
